ischarge: Single battery over-discharge voltage: 2.7V±0.08V
Continuous working current: 25A
Instant protection current: 60A
Overcurrent recovery conditions: charge recovery or disconnect load
Short-circuit recovery conditions: charge recovery or disconnect load
Charge
Single battery overcharge voltage: 4.25V±0.025V
Continuous charging current: 20A
Charge equalization voltage: 4.15V±0.025V
Charge equalization current:40mA
Charger voltage: 30V (recommended)
Charging over temperature protection: 50℃
Discharge over temperature protection: 70℃
Working power consumption: ≤30uA
Main circuit conduction internal resistance: ≤20mΩ
Temperature range: -40 to 80℃
Wire break protection: Yes
Wire Length: 40cm
Appearance size: 60 x 33 x 7MM
Connection method: Common Port
Due to different product batches, the appearance may be different, but the function is the same
color:As shown
Material:PC+Metal
